CDF7000
MULTI-RANGE LEAKAGE CALIBRATOR
The CDF7000 enables calibration checks for leak and flow measurement instruments, as well as calibrated leaks and jets.
This portable, user-friendly device offers precise adjustment of leak or flow rates with real-time display readings. It ensures product quality and compliance with standards like ISO 9001.
HIGHLIGHTS
- PORTABLE AND COMPACT INSTRUMENTS
- LI-ION BATTERY
- MEASURE: FLOW, PRESSURE, TEMPERATURE
- PRESSURE AND VACUUM MEASUREMENT
- COMMUNICATION WITH ATEQ DEVICES (D/G/F OF S6-S7)
- MULTIRANGE SOLUTIONS (4+1)
ATEQ LEAK/FLOW TESTERS
Calibration check for ATEQ Leak Testers
COMPETITOR LEAK/FLOW TESTERS
Check of any other type of Leak Detectors
LEAK TEST FIXTURES
Allows check of Leak Test Fixtures
ENVIRONMENT
- ROHS standard
FLEXIBLE COMMUNICATION FORMAT
- RS232: Printer, Modbus RTU
- Slave USB: PC Supervision (WinAteq 300, sesame)
- Master USB: USB Key to Transfer (parameters, results…)
Additional:
Time & date, Language & Units Choice, Test Customization & More…
- Measurement in actual or standard conditions
- Different displays available (bargraph – curves)
- USA / SI units
- New ergonomy
- User-friendly interface
- Easy connection to the test instruments
- Time and date function
- Print out (USB or RS232)
OTHERS
- Improved resolution compared to previous CDF
- More than 8h battery lifetime
- Strong carry case
- Can be used for field as well as laboratory checks
MEASUREMENT RANGES:
CDF 7000: Vacuum and Pressure Measurement Specifications (All Ranges)
| Measurement | Specification | Value |
|---|---|---|
| Flow | Precision* | 0-100%FS: ±1.25% Rdg + 0.1%FS |
| Temperature Drift | ± 0.05% Rdg /°C | |
| Long-term Drift | +/- 0.5% FS (pending) | |
| Pressure | Precision* | +/- (1.5% Rdg + 0.15% FS) |
| Resolution | 0.1 mbar | |
| ATM P | Precision | +/- (1% Rdg + 0.3% FS) |
| Resolution | 0.1 mbar | |
| Temperature | Precision | ± 0.5°C |
| Resolution | 0.1°C |
* Linearity + Repeatability + Hysteresis
TECHNICAL SPECIFICATIONS:
| SPECIFICATIONS | |
|---|---|
| Physical | Weight: Approximately 5 kg Without handle (in mm): H 215 x D 170 x L 220 |
| Interface | 7″ LCD Touch Screen |
| External electrical supply | 28 V DC / 4 A Battery Li-ion 24 V / 4 A |
| Air Supply | Clean and dry air required Air quality standard to be applied (ISO 8573-1) |
| Temperature | Operating: +5° C to +45°C Storage: 0°C to +60°C |
Detailed information about the CDF7000 including features, specifications, etc.
CDF7000 Brochures – English OPTION
- 4 standard ranges + 1 in option
ACCESSORIES
- USB Cord
