APPLICATION
EMOBILITY
AUTOMOTIVE
- Air Conditioning
- Radiators
- Exhaust
- Transmission…
PACKAGINGS
- Aerosol Caps
- Plastic Bags
- Sprays
- Plastic Bottles...
ELECTRONICS
- Hard Disk
- Watches
- TV Screen
- Camera Lenses…
MEDICAL
FEATURES
- GENERAL
- Cold Start-Up, less than 3 minutes
- Standby Start-Up, less than 1 minute
- One button automatic operation
- Hard vacuum leak detection system
- Modular assembly for custom arrangement
- PLC controlled
- Turn-key operation
- Front panel key lock-out
- Turbo speed adjustable from 600 to 1500HZ
- Five year warranty on major components
- Includes an internal fast clean-up sniffer manifold
- Allows rapid switching between sniff and vacuum testing modes
- Auto peak cycle
TEST MODES
- System Mode, minimum detectable helium leak rate 2.5 x 10-9 atm-cc/sec
- Sniffer Mode, minimum detectable helium leak rate 2.5 x 10-7 atm- cc/sec
- Response Time: < 1.0 second system mode testing, < 1.5 seconds sniffer mode testing
- Startup Time: One button automatic operation
- Cold Start-Up, less than 3 minutes.
- Standby Start-Up, less than 1 minute
SPECIFICATIONS
- ELECTRICAL SUPPLY
-
115/220 Volts AC, 60/50 Hz, 4 Amps (other voltages available upon request)
-
- PHYSICAL
- Weight: 31.8 Kg
- Dimensions: (WxHxD) W344xH395xD618 mm
- VALVE
-
115/220 Volts AC, 60/50 Hz, 4 Amps (other voltages available upon request)
-
- PRESSURE MEASUREMENT
- Connection gage for rough vacuum (atm-10-3 Torr),Turbo pump speed characteristics for high vacuum (10-6 Torr)
- INLET SYSTEM
-
External PLC controlled valves, externally mounted. Options: DC or AC
-
- HIGH VACUUM PUMP
- 53 c/second air-cooled turbo-molecular
- MECHANICAL PUMP
-
External forepump arrangement, standard package with 7 CFM
-
OPTIONS
ADD-ONS
- 24vDC Control
- 110vDC Control
- Atmospheric Sniffer Module
- Side Mount Configuration
- Bottom Mount Configuration
- Electrical Converter Box
